JC Industrial Counting Scales. 3kg, 6kg, 15kg, 30kg, 45kg
JC Series Dual Counting Scales
- Capacities to 45kg
- 20mm LCD display,white color LED backlight
- External resolution up to 60,000
- Functions include accumulating, preset count with alarm, up to 100 PLUs with description, unit & tare weight
JC Series Options
- RS-232 can connect to a computer or external printer
- Dual channel interface to connect an external platform
JC Industrial Counting Scales Specifications:
| MODEL |
JC-3
|
JC-6
|
JC-15
|
JC-30
|
JC-45
|
|||||
| Capacity |
3kg
|
6kg
|
15kg
|
30kg
|
45kg
|
|||||
| Readability |
0.1g
|
0.2g
|
0.5g
|
1g
|
1g
|
|||||
| Tare range |
3kg
|
6kg
|
10kg
|
30kg
|
45kg
|
|||||
| Display |
20mm digit high LCD,white color LED backlight
|
|||||||||
| Operate temp |
0°C~+40°C
|
|||||||||
| External resolution |
1/30,000
|
|||||||||
| ADC |
sigma delta
|
|||||||||
| ADC update |
≤1/10 seconds
|
|||||||||
| Internal counts |
600,000
|
|||||||||
| Rating |
AC adapter 9V 800mA &/or Internal rechargeable battery(6V/4Ah)
|
|||||||||
| Pan size |
240mm x 350mm
|
|||||||||
| Keyboard |
25 mechanical keys
|
|||||||||
| Overload capacity |
150% of rated capacity
|
|||||||||
| Gross weight |
5.8kg
|
|||||||||
Quotes?
For quotes for the JC Series Counting Scales, please select the GET A QUOTE tab above.
More information?
If you require more information regarding counting scales, feel free to get in contact by calling us on 1300 722 537 or use our online contact form to send us a message & we will be happy to try to help you find the right counting scale for your requirements. And remember, we can also provide repair, calibration & certification services for your scales.
